model

 HEX-BLDC-010

hall sensor

 Without Holzer sensor

Rated voltage

 5V/12V/24V

electric current

 No-load current: 0.5A, load current: 1A

Start-up time

 0.2s~0.3s

speed

 No-load speed: 5000~10000RPM, load speed: 8000RPM

Torsion

 300g.cm

PCB size

 Outside diameter 5mm, inner diameter PCB 27mm built-in (size can be customized)

Incidental function

 Over current protection, blocking protection, under voltage protection, CW\CCW, speed regulation function

application area

 Air purifier motor, brushless DC pump, hair brush, home appliance

model

 HEX-BLDC-019

hall sensor

 Without Holzer sensor

Rated voltage

 7.4V

electric current

 5A

Start-up time

 0.2s~0.3s

speed

 6000RPM

PCB size

 Outside diameter 26mm, inner diameter 6mm, PCB built-in (size can be customized)

Incidental function

 Over current protection, blocking protection, under voltage protection, CW\CCW, speed regulation function

application area

 Air purifier motor, brushless DC pump, hair brush, home appliance
